What is the production equipment for medicinal aluminum tube?

1、 What is the production equipment for medicinal aluminum tube?

Aluminum tube punching machine, also known as cold extrusion press, is the main production equipment for medicinal aluminum tubes. Can be used for extrusion molding process of non-ferrous metals. Widely used in aluminum products industries such as aluminum cans, capacitor aluminum shells, air conditioning aluminum tubes, aluminum tube, chemical packaging aluminum shells, etc. The cold extrusion press has automatic feeding and discharging, automatic circulation lubrication system, etc. Produce every minute based on factors such as product length, material, and workpiece size.

2、 What is an automated production line for medicinal aluminum tube

The production equipment for medicinal aluminum tubes mainly consists of aluminum tube machines, threading machines, annealing furnaces, bottom printing machines, color printing machines, supply rooms, and capping machines connected in series to form an automatic production line.

High quality (99.73%) aluminum discs that have been annealed are fed into a stamping machine mold and cold extruded into tube blanks under pressure. The threaded head and tail are cut off with a threading knife and sent to an annealing furnace. The aluminum tube is softened at a temperature of 45D-48D ', and then coated, cured, primer, and dried before printing on the blank tube. First print the base color, then print the color. Use a far-infrared drying room to remove any dissolved substances from the coating, and the coating will dry into a film. The colored tube is capped by a capping machine.

3、 The main workflow of the horizontal stamping machine for medicinal aluminum tube

The aluminum discs are automatically sorted and regularly fed into the feeding guide rail by the vibrating hopper. The discs are accurately fed into the stamping cavity by the feeding robot arm. Under the action of the mold, the discs are cold extruded in one go, forming a billet tube and automatically discharging it. The billet tube is output in an orderly manner through the conveyor chain. The conveyor chain can be connected to the feeding chute of the threading machine and automatically enter the next production process. The horizontal stamping machine for medicinal aluminum tube is equipped with an automatic oil pump lubrication system. The oil pump must be started before the machine starts working, and the machine can only be started after the oil pump is working, otherwise the machine cannot be started. Automatic lubrication points are installed in the crankshaft, guide rail, flywheel and other parts.

4、 Characteristics of horizontal stamping machine for medicinal aluminum tube

1. The medicinal aluminum tube filling machine adopts cylinder braking, which is easy to operate, safe and efficient.

The punch seat adopts a double inclined adjustment form, with accurate positioning. The punch seat and connecting rod adopt an adjustable structure, which can eliminate the gap caused by long-term wear and tear of the equipment, ensuring the long-term working accuracy of the equipment. High quality copper materials are used for key parts such as copper bearings and guide rails to reduce friction coefficient, increase wear resistance, and extend the service life of the machine; The crankshaft has been equipped with flat bearings, which prevent forward and backward movement and improve the working accuracy of the equipment. The connecting rod and distance adjustment connecting rod are both processed by CNC equipment, greatly improving the machining accuracy. The film delivery adopts a mechanical arm structure, which is stable and convenient.

2. The overall structure is reasonable, the operation is smooth, the vibration is small, the noise is low, the service life is long, the adjustment is convenient, the operation is easy, safe and efficient, especially suitable for long-term continuous production.

3. The embryo tube automatically outputs in an orderly manner, equipped with a lubrication protection system, does not work without lubrication, cylinder braking, fast and safe, low vibration, low noise, and easy adjustment.
